1 or 2x Intel® Xeon® 6700P-series or 6500P-series processors (P-cores), up to 86 cores / 172 threads, up to 4.0 GHz, up to 350W TDP
Memory
32x DDR5 DIMM slots (16 per CPU), 8 channels/CPU, 2 DPC. RDIMMs up to 6400 MHz (1 DPC) / 5200 MHz (2 DPC); MRDIMMs up to 8000 MHz (1 DPC); up to 8TB using 32x 256GB 3DS RDIMMs
CXL Memory
Supports CXL 2.0 memory DIMMs in E3.S 2T form factor, up to 12x DIMMs with two processors
Storage Drives
Up to 40x 2.5", 16x 3.5", or 32x E3.S hot-swap drive bays (front: up to 24x 2.5"/12x 3.5"/32x E3.S; mid: 8x 2.5" simple-swap; rear: up to 8x 2.5"/4x 3.5"); up to 36x NVMe drives without oversubscription (1:1 connectivity)
PCIe Slots
Up to 10x rear PCIe 5.0 slots + 2x dedicated OCP 3.0 slots (PCIe 5.0 x8/x16)
GPU Support
Up to 10x single-wide GPUs or 2x double-wide GPUs. (For 4x double-wide GPUs with NVLink, see the ThinkSystem SR650a V4.)
